setcapacity

Purpose
Sets the maximal capacity (the maximal amount of processing units available) of a discrete resource between two time bounds. This routine can only be applied to resources of type KALIS_DISCRETE_RESOURCE.
Synopsis
procedure setcapacity(resource:cpresource, tmin:integer, tmax:integer, capa:integer)
Arguments
resource
the resource
tmin
lower bound of the time interval
tmax
upper bound of the time interval
capa
the maximal amount of processing units available of resource in the interval [tmin,tmax]
Example
The following example shows how to use setcapacity:
Scheduling/ResourceCapacity.png
model "Resource capacity"
 uses "kalis"

 declarations
  A, B, C : cptask            ! Declaration of tasks
  resource : cpresource       ! Declaration of resource
 end-declarations

 setname(A,"A"); setname(B,"B"); setname(C,"C")

! The resource is a cumulative resource with maximum capacity 6
 set_resource_attributes(resource, KALIS_DISCRETE_RESOURCE, 6)

! Setting the resource capacity in the interval 0..2 to 3
 setcapacity(resource, 0, 2, 3)
! Setting the resource capacity in the interval 3..4 to 2
 setcapacity(resource, 3, 4, 2)
! Setting the resource capacity in time period 5 to 1
 setcapacity(resource, 5, 5, 1)

! Setting the task durations
 set_task_attributes(A, 1)
 set_task_attributes(B, 2)
 set_task_attributes(C, 3)

! Setting the resource requirements of the tasks
 requires(A, 1, resource)
 requires(B, 2, resource)
 requires(C, 3, resource)

! Find the optimal schedule (minimizing the makespan)
 if cp_schedule(getmakespan) <> 0 then
  cp_show_sol
 else
  writeln("no solution found")
 end-if

end-model
